Pneumonia Detector using Computer Vision

This project uses the DenseNet121 model to detect pneumonia in chest X-ray images. The model is trained on a dataset with train, validation, and test splits from kaggle and demonstrates the use of transfer learning and data augmentation in PyTorch.

---

Table of Contents

1. Dataset Overview
2. Model Architecture
3. Implementation
4. Training
5. Evaluation
6. Results
7. Future Work

---

Dataset Overview

The dataset is structured as follows:

dataset/
├── train/
│   ├── NORMAL/
│   └── PNEUMONIA/
├── val/
│   ├── NORMAL/
│   └── PNEUMONIA/
└── test/
    ├── NORMAL/
    └── PNEUMONIA/

Each folder contains JPEG images of chest X-rays.
You can download a similar dataset from Kaggle Chest X-Ray Images

---

Model Architecture

The model uses DenseNet121, a pre-trained model available in torchvision.models. Its final layer is replaced with a fully connected layer for binary classification.

model = models.densenet121(pretrained=True)
num_features = model.classifier.in_features
model.classifier = nn.Linear(num_features, 2)  # Binary classification (NORMAL vs PNEUMONIA)

---

Implementation

Here is the Python implementation of the project:

Data Preparation and Pre-Processing

from torchvision import datasets, transforms
from torch.utils.data import DataLoader

train_dir = "/training_dataset"
val_dir = "/val_dataset"
test_dir = "/test_dataset"

# Image transformation
data_transforms = {
    'train': transforms.Compose([
        transforms.Resize((224, 224)),
        transforms.RandomHorizontalFlip(),
        transforms.ToTensor(),
        transforms.Normalize([0.485, 0.456, 0.406], [0.229, 0.224, 0.225])
    ]),
    'val': transforms.Compose([...]),
    'test': transforms.Compose([...]),
}

# datasets
datasets_dict = {
    'train': datasets.ImageFolder(train_dir, transform=data_transforms['train']),
    'val': datasets.ImageFolder(val_dir, transform=data_transforms['val']),
    'test': datasets.ImageFolder(test_dir, transform=data_transforms['test']),
}

# dataloaders
dataloaders = {
    'train': DataLoader(datasets_dict['train'], batch_size=32, shuffle=True),
    'val': DataLoader(datasets_dict['val'], batch_size=32, shuffle=False),
    'test': DataLoader(datasets_dict['test'], batch_size=32, shuffle=False),
}

Training

import time
from tqdm import tqdm

def train_model(model, dataloaders, criterion, optimizer, num_epochs=5):
    for epoch in range(num_epochs):
        print(f"Epoch {epoch + 1}/{num_epochs}")
        for phase in ['train', 'val']:
            model.train() if phase == 'train' else model.eval()

            running_loss = 0.0
            running_corrects = 0
            total_samples = 0

            with tqdm(dataloaders[phase], unit="batch") as tepoch:
                for inputs, labels in tepoch:
                    tepoch.set_postfix(loss=..., accuracy=...)

---

Training

Run the training script to train the DenseNet121 model for 5 epochs:

python main.py

During training, the script displays a progress bar and updates metrics like loss and accuracy.

---

Evaluation

The test dataset is used to evaluate the trained model:

def evaluate_model(model, dataloader):
    model.eval()
    with torch.no_grad():
           for inputs, labels in dataloader:
                inputs, labels = inputs.to(device), labels.to(device)
                outputs = model(inputs)
                _, preds = torch.max(outputs, 1)
                running_corrects += torch.sum(preds == labels.data)
                total_samples += labels.size(0)

        accuracy = running_corrects.double() / total_samples
        print(f"Test Accuracy: {accuracy:.4f}")

---

Results

Sample Metrics

• Validation Accuracy: 98.2%
• Test Accuracy: 87.6%

---

Images

Example Input

---

Future Work

1. Hyperparameter optimization for better accuracy.
2. Explore additional augmentation techniques.
3. Deploy the model as a web application using Flask or FastAPI.
4. Experiment with other models like ResNet or EfficientNet.

---

References

• DenseNet121 Documentation
• Chest X-Ray Dataset
• PyTorch Tutorial
