NeuroPersona: Simulation of Dynamic Cognitive Perspectives

Version: 1.3

Introduction

NeuroPersona is not a static analysis tool, but a bio-inspired simulation platform designed to replicate the dynamic and often variable processes of human cognition and emotion when engaging with a topic or question. Instead of producing a single, deterministic answer, NeuroPersona explores different plausible "thought paths" or "perspectives" that may emerge in response to a given input.

The system models interacting cognitive modules (creativity, criticism, simulation, etc.), an adaptive value system, a dynamic emotional state (based on the PAD model), and neural plasticity.
Each simulation run represents a unique snapshot of a possible cognitive/affective state.

Core Philosophy: Simulation Over Prediction

NeuroPersona’s approach differs fundamentally from traditional AI models:

1. Variability as a Feature:
   The system is inherently non-deterministic. Repeated runs with the same input will produce different yet internally plausible end states due to random weight initialization, stochastic activation noise, emotional dynamics, and path-dependent learning and plasticity processes.
   This mirrors the natural variability of human thinking.

2. Emergent Perspectives:
   Each simulation run can be seen as a unique "thought process" prioritizing different aspects of a topic (sometimes innovation, sometimes safety, sometimes fundamentals).
   The result is not "right" or "wrong" — it is a simulated, plausible perspective.

3. State Interpretation:
   The goal is to understand the final cognitive and emotional state within a single run:

   • Which internal values dominate?
   • Which cognitive modules are most active?
   • What is the overall emotional tone?
   • Is the state internally coherent (e.g., high creativity paired with high innovation value)?
   • Apparent "inconsistencies" (e.g., high criticism activity but low safety value) are valid results, representing certain cognitive "stances" (such as decoupling analysis from prioritization).

4. Exploration of Possibility Space:
   By simulating multiple runs (optionally with slightly varied parameters), you can explore the space of possible cognitive reactions to a topic, rather than focusing on a single definitive answer.

Key Features

• Dynamic Input Processing:
  Utilizes a (simulated) "Perception Unit" to transform user prompts into structured data.

• Modular Cognitive Architecture:
  Simulates interacting modules:

  • CortexCreativus: Idea generation and associative thinking.
  • CortexCriticus: Analysis, evaluation, and risk assessment.
  • SimulatrixNeuralis: Scenario thinking and mental simulation.
  • LimbusAffektus: Dynamic emotional state modeling (Pleasure, Arousal, Dominance).
  • MetaCognitio: Monitoring of network states and adaptive strategic adjustments (e.g., learning rate tuning).
  • CortexSocialis: Modeling of social influence factors.

• Adaptive Value System:
  Internal values (e.g., innovation, safety, ethics) influence behavior and dynamically adjust through simulation.

• Neural Plasticity:
  Simulates structural changes (connection pruning and sprouting) and activity-dependent learning (Hebbian learning, reinforcement).

• Stochasticity:
  Purposeful use of randomness to emulate biological variability.

• Persistent Memory:
  Long-term storage and retrieval of relevant information via SQLite database.

• Reporting and Visualization:
  Generates detailed HTML reports and plots analyzing network dynamics and end states.

• Orchestration:
  The orchestrator.py script controls the complete workflow from prompt to final enriched response (optionally integrating an external LLM API like Gemini).

Workflow Overview (orchestrator.py)

1. Perception:
   A user prompt is converted into structured data (simulated CSV/DataFrame) via gemini_perception_unit.py.

2. Cognition/Simulation:
   This data is fed into neuropersona_core.py. The network is initialized and simulated over a number of epochs, where learning, emotions, values, and plasticity interact.

3. Synthesis (Optional):
   The results (report, structured data) are used to generate a final, contextually enriched answer, potentially involving an external LLM API (generate_final_response in orchestrator.py).

Technical Components (neuropersona_core.py)

• Classes:
  Node, MemoryNode, ValueNode, Connection, specialized module classes (as listed above), PersistentMemoryManager.

• Core Functions:
  simulate_learning_cycle, calculate_value_adjustment, update_emotion_state, hebbian_learning, apply_reinforcement, prune_connections, sprout_connections, generate_final_report, create_html_report, plotting utilities.

• Parameters:
  Numerous constants control learning rates, decay rates, thresholds, emotional dynamics, and allow fine-tuning of system behavior.

Installation

1. Clone the Repository:

   git clone <repository-url>
   cd <repository-folder>

2. Create a Virtual Environment (recommended):

   python -m venv venv
   # Windows
   venv\Scripts\activate
   # MacOS/Linux
   source venv/bin/activate

3. Install Dependencies:
   (Make sure a requirements.txt exists)

   pip install -r requirements.txt
   # Required: pandas, numpy, matplotlib
   # Optional: networkx, tqdm, google-generativeai

4. Set API Key (Optional):
   If you want to use full orchestration with external LLM (e.g., Gemini):

   # Windows (PowerShell)
   $env:GEMINI_API_KEY="YOUR_API_KEY"
   # Windows (CMD)
   set GEMINI_API_KEY=YOUR_API_KEY
   # MacOS/Linux
   export GEMINI_API_KEY='YOUR_API_KEY'

Usage

You can run a full simulation either through the GUI or directly through the orchestrator:

• Start GUI:

  python neuropersona_core.py

  (The GUI allows you to enter prompts, adjust key simulation parameters, and start the full workflow.)

• Run Orchestrator Directly:

  python orchestrator.py

  (The script will prompt you for input if run directly.)

Interpreting Results

Remember the core philosophy:

• Focus on Single Run Interpretation:
  Analyze the generated HTML report and plots for this specific simulation run.

• Look at the State:
  How do dominant categories, module activities, values, and emotions interact? Is the resulting "profile" internally coherent?

• Avoid Rigid Comparisons:
  Do not expect identical results between runs. Observe the range of plausible states.

• Value Saturation (Values at 1.0):
  Often a sign of rapid learning given limited data. Interpret this as "maximum relevance in this run," while recognizing that differentiation at the top end is lost.

• "Inconsistencies" are Valid:
  If, for example, Cortex Criticus is highly active while the Safety value remains low, it still represents a valid cognitive stance — not an error.

Key Parameters (neuropersona_core.py Constants)

• DEFAULT_EPOCHS: Number of simulation cycles.
• DEFAULT_LEARNING_RATE: Base learning rate.
• DEFAULT_DECAY_RATE: Rate of activation/weight decay without input (important against saturation).
• VALUE_UPDATE_RATE: Speed of internal value adjustments.
• EMOTION_UPDATE_RATE, EMOTION_DECAY_TO_NEUTRAL: Control emotional dynamics.
• PRUNING_THRESHOLD, SPROUTING_THRESHOLD: Control structural plasticity.

Fine-tuning these parameters (via GUI or settings files) affects the dynamics and differentiation capability of the system.

📖 Analogy for Non-Scientists: How NeuroPersona "Thinks"

Imagine you ask a calculator, "What is 2 + 2?" — you always get "4". That’s a deterministic system.

NeuroPersona is different. Imagine asking a person a complex question like:
"Should we heavily invest in a new, risky technology?"

• On Day 1, feeling optimistic and inspired by success stories, the answer might be:
  "Absolutely! Huge opportunities — we must innovate!" (Focus: innovation, opportunity).

• On Day 2, after reading about similar failures and feeling cautious, the answer could be:
  "Careful! We must assess risks first and ensure ethical responsibility." (Focus: safety, ethics, risk assessment).

• On Day 3, feeling highly analytical, the person might say:
  "Let's first analyze the fundamentals and long-term efficiency impacts." (Focus: fundamentals, efficiency).

All these answers are plausible human reactions, depending on internal "mood" (emotions), "priorities" (values), and currently salient information.

NeuroPersona replicates exactly this kind of variability:

• It has internal "moods" (emotions) that shift.
• It has "priorities" (values) that evolve.
• Randomness (noise) influences thought paths.
• Learning continuously reshapes connections.

Thus, if NeuroPersona delivers different outcomes across runs, it’s not an error — it’s a feature.
It simulates different but coherent cognitive perspectives, illustrating the diversity of plausible cognitive-emotional responses to a problem.

Diagramm 1: GUI & Workflow-Start

graph TD
    %% =============================================
    %% == 1. GUI & Initialisierung               ==
    %% =============================================
    StartApp["User startet neuropersona_core.py"] --> CallStartGUI["rufe start_gui()"]
    %% ^-- Text in Anführungszeichen, Kommentar auf neuer Zeile
    CallStartGUI --> InitGUI["Initialisiere Tkinter GUI"]
    InitGUI --> LoadSettingsCheck{"Existiert<br>settings.json?"}
    LoadSettingsCheck -- Ja --> CallLoadGUISettings["rufe load_gui_settings()"]
    CallLoadGUISettings --> UpdateGUIWidgets["Update GUI-Widgets"]
    UpdateGUIWidgets --> GUIReady["GUI bereit"]
    LoadSettingsCheck -- Nein --> GUIReady

    GUIReady --> UserInteraction["User Interaktion"]
    UserInteraction -- Klick 'Params speichern' --> CallSaveGUISettings["rufe save_gui_settings()"]
    CallSaveGUISettings --> WriteJSON["Schreibe JSON"]
    WriteJSON --> GUIReady
    UserInteraction -- Klick 'Params laden' --> CallLoadGUISettings
    UserInteraction -- Klick 'Workflow starten' --> CallStartWorkflowAction["rufe start_full_workflow_action()"]

    CallStartWorkflowAction --> GetGUIInput["Hole GUI-Input"]
    GetGUIInput --> ValidateInput{"Input gültig?"}
    ValidateInput -- Nein --> ShowErrorMsg["Zeige Fehler"]
    ShowErrorMsg --> GUIReady
    ValidateInput -- Ja --> DisableStartButton["Deaktiviere Start-Button"]
    DisableStartButton --> CreateWorkflowThread["Erstelle & Starte Workflow Thread<br>(run_workflow_in_thread)"]
    CreateWorkflowThread --> UpdateGUIStatusInit["Update GUI Status: 'Starte...'"]
    CreateWorkflowThread --> ToDiagram2["(Siehe Diagramm 2: Workflow Thread)"]

    %% Ende dieses Diagramms

Diagramm 2: Workflow Thread & Orchestrator (High-Level)

graph TD
    %% =============================================
    %% == 2. Workflow Thread & Orchestrator       ==
    %% =============================================
    WFThreadStart("Workflow Thread Start<br>(run_workflow_in_thread)") --> ImportOrchestrator{"Importiere<br>orchestrator?"}
    ImportOrchestrator -- Nein --> WF_ERR_Import["Fehler"] --> UpdateGUIStatusErrorImp["Update GUI Status"] --> WFThreadEndError(Error End)
    ImportOrchestrator -- Ja --> GetExecFunc["Hole execute_full_workflow"]
    GetExecFunc --> CallOrchestrator["Rufe orchestrator.execute_full_workflow"]

    subgraph Orchestrator_Execute [Orchestrator: execute_full_workflow]
        direction TB
        OrchStart(Start) --> Step1_InputData["Schritt 1:<br>get_input_data"]
        Step1_InputData --> ValidateInputDF{"Input DF OK?"}
        ValidateInputDF -- Nein --> Orch_ERR_InputData["Error"] --> OrchEndError(Error)
        ValidateInputDF -- Ja --> Step2_NeuroPersona["Schritt 2:<br>run_neuropersona<br>(Siehe Diagramm 3)"]
        Step2_NeuroPersona --> ValidateNPResults{"NP Results OK?"}
        ValidateNPResults -- Nein --> Orch_ERR_NPSim["Error"] --> OrchEndError
        ValidateNPResults -- Ja --> CheckGeminiConfig{"Gemini API OK?"}
        CheckGeminiConfig -- Nein --> SkipGemini["Nutze NP-Bericht<br>als Fallback"] --> OrchEndSuccess(Result)
        CheckGeminiConfig -- Ja --> Step3_SynthesizeResponse["Schritt 3:<br>generate_final_response<br>(Siehe Diagramm 4)"]
        Step3_SynthesizeResponse --> SynthResult{"Synthese OK?"}
        SynthResult -- Ja --> OrchEndSuccess
        SynthResult -- Nein --> Orch_ERR_Synth["Error"] --> OrchEndError
    end

    CallOrchestrator --> Orchestrator_Execute
    Orchestrator_Execute -- Success --> WF_ReceiveResult["Empfange Resultat"] --> UpdateGUIStatusSuccess["Update GUI Status"] --> CallDisplayResult["-> display_final_result<br>(Siehe Diagramm 5)"] --> WFThreadEndSuccess(End)
    Orchestrator_Execute -- Error --> WF_ReceiveError["Empfange Fehler"] --> UpdateGUIStatusError["Update GUI Status"] --> CallDisplayResult --> WFThreadEndError

    %% Ende dieses Diagramms

Diagramm 3: NeuroPersona Core Simulation (High-Level & Loop)
(Hier könntest du entscheiden, wie viel Detail du aus der simulate_learning_cycle-Schleife zeigen willst. Vielleicht nur die Hauptphasen A-O als Kette?)

graph TD
    %% =============================================
    %% == 3. NeuroPersona Core Simulation         ==
    %% =============================================
    Call_run_np_simulation("Aufruf:<br>neuropersona_core.run_neuropersona_simulation") --> NP_Start(Start)
    NP_Start --> NP_Preprocess[preprocess_data]
    NP_Preprocess --> NP_InitNodes[initialize_network_nodes]
    NP_InitNodes --> NP_CallSimulateCycle[rufe simulate_learning_cycle]

    subgraph Simulation_Loop [Epochen-Schleife: simulate_learning_cycle]
        direction TB
        LoopInit["Init & Connect"] --> LoopStart["Epoche Start"]
        LoopStart --> Phases_A_to_O["Phasen A-O:<br>Reset, Input, Propagate,<br>Update Activation/Emotion/Values,<br>Modules, Learning, Decay,<br>Plasticity?, Consolidation?, Interpret"]
        Phases_A_to_O --> NextEpoch{"Nächste Epoche?"}
        NextEpoch -- Ja --> LoopStart
        NextEpoch -- Nein --> EndSimLoop["Ende Epochen"]
    end

    NP_CallSimulateCycle --> Simulation_Loop
    Simulation_Loop --> ReceiveSimResults["Empfange Ergebnisse"]
    ReceiveSimResults --> NP_GenerateReport["generate_final_report"] --> ReceiveReportAndStruct["Empfange Bericht & Struct"]
    ReceiveReportAndStruct --> CheckPlots{"Plots?"}
    CheckPlots -- Ja --> NP_GeneratePlots["Generiere Plots"] --> PostPlotActions
    CheckPlots -- Nein --> PostPlotActions
    PostPlotActions --> CheckSaveState{"Speichern?"}
    CheckSaveState -- Ja --> NP_SaveState[save_final_network_state] --> NP_CreateHTML[create_html_report]
    CheckSaveState -- Nein --> NP_CreateHTML
    NP_CreateHTML --> ReturnNPResults["Return Bericht & Struct"] --> NP_End(End)

    %% Ende dieses Diagramms

Diagramm 4: Antwort-Synthese (Gemini)

graph TD
    %% =============================================
    %% == 4. Antwort-Synthese (Gemini)            ==
    %% =============================================

    %% == 1. NODES DEFINITION ==
    Call_generate_final_response("Aufruf:<br>orchestrator.generate_final_response")
    InputCollectionPhase["1. Input Sammlung"]
    PromptCreationPhase["2. Prompt Erstellung"]
    GeminiProcessingPhase["3. Gemini API Verarbeitung"]
    ResultHandlingPhase["4. Ergebnis Verarbeitung"]
    ToDiagram2_Success["(Zurück zu Diagramm 2 - Erfolg)"]
    ToDiagram2_Error["(Zurück zu Diagramm 2 - Fehler)"]

    %% Nodes within Input_Sammlung Subgraph
    subgraph Input_Sammlung_Details [Details: Input Sammlung]
        direction LR
        IS_UserInput["Original User Prompt"]
        IS_NPReport["NeuroPersona Bericht<br>(Kontext)"]
        IS_NPStruct["Strukturierte NP Ergebnisse<br>(Dominanz, Modullevel...)"]
    end

    %% Nodes within Prompt_Erstellung Subgraph
    subgraph Prompt_Erstellung_Details [Details: Prompt Erstellung]
        direction TB
        PE_ExtractKeyResults["Extrahiere dominante Kat.,<br>Modullevel aus NP Struct"]
        PE_AssemblePrompt["Baue Prompt zusammen:<br>Inputs + **Instruktionen**(...)"]
    end

    %% Nodes within Gemini_Verarbeitung Subgraph
    subgraph Gemini_Verarbeitung_Details [Details: Gemini API Verarbeitung - Blackbox]
        direction TB
        GV_CallGeminiAPI["Sende Prompt an<br>Gemini API"]
        GV_InternalGeminiProcess{{"**Gemini LLM<br>(Inferenz)**<br><br><i>Verarbeitet Prompt...</i>"}}
    end

    %% Nodes within Ergebnis_Handhabung Subgraph
    subgraph Ergebnis_Handhabung_Details [Details: Ergebnis Verarbeitung]
         direction TB
         EH_HandleGeminiResponse{"Empfange Antwort<br>von API"}
         EH_CheckResponse{"Antwort OK<br>& nicht blockiert?"}
         EH_ExtractText["Extrahiere finalen<br>Antwort-Text"]
         EH_FormatError["Formatiere<br>Fehlermeldung"]
         EH_EndSuccess(Finaler Antworttext)
         EH_EndError(Fehlermeldung)
    end

    %% == 2. LINKS DEFINITION ==

    %% Hauptfluss zwischen den Phasen
    Call_generate_final_response --> InputCollectionPhase
    InputCollectionPhase --> PromptCreationPhase
    PromptCreationPhase --> GeminiProcessingPhase
    GeminiProcessingPhase --> ResultHandlingPhase

    %% Verbindungen zu und innerhalb Subgraph 1: Input Sammlung
    %% Von Hauptphase zum ersten internen Knoten
    InputCollectionPhase --> IS_UserInput
    IS_UserInput --> IS_NPReport
    IS_NPReport --> IS_NPStruct

    %% Verbindungen zu und innerhalb Subgraph 2: Prompt Erstellung
    %% Von Hauptphase zum ersten internen Knoten
    PromptCreationPhase --> PE_ExtractKeyResults
    PE_ExtractKeyResults --> PE_AssemblePrompt

    %% Verbindungen zu und innerhalb Subgraph 3: Gemini Verarbeitung
    %% Von Hauptphase zum ersten internen Knoten
    GeminiProcessingPhase --> GV_CallGeminiAPI
    GV_CallGeminiAPI --> GV_InternalGeminiProcess

    %% Verbindungen zu und innerhalb Subgraph 4: Ergebnis Handhabung
    %% Von Hauptphase zum ersten internen Knoten
    ResultHandlingPhase --> EH_HandleGeminiResponse
    EH_HandleGeminiResponse --> EH_CheckResponse
    EH_CheckResponse -- Ja --> EH_ExtractText
    EH_ExtractText --> EH_EndSuccess
    EH_CheckResponse -- Nein --> EH_FormatError
    EH_FormatError --> EH_EndError

    %% Finale Verbindungen zu den Endpunkten
    EH_EndSuccess --> ToDiagram2_Success
    EH_EndError --> ToDiagram2_Error

    %% Ende dieses Diagramms

Diagramm 5: GUI Post-Workflow

graph TD
    %% =============================================
    %% == 5. GUI Post-Workflow                   ==
    %% =============================================
    FromWorkflowThread("... vom Workflow Thread<br>(via root.after)") --> DisplayResultWindow["display_final_result:<br>Zeige Ergebnis-Fenster"]
    DisplayResultWindow --> UserClosesWindow{"User schließt Fenster?"}
    UserClosesWindow --> ReEnableStartButton["Reaktiviere Buttons<br>(im finally Block des Threads)"]
     ReEnableStartButton --> GUIIdle["GUI wieder bereit"]

    %% Ende dieses Diagramms
